Features
Specifications
For Oxygen
Model | PS-2OP-N | PS-2OE-Ex |
Target Gas | Oxygen | |
Sensor Type | Diaphragm galvanic cell | |
Detection Method | Pump suction type | Ejector suction type |
Detection Range | According to separate specifications | |
Compatible Cables | 2-core+2-core shield | 2-core shield |
Extendible distance | 2mm2 cable less than 1km | 500m or less with 2mm2 cable |
Approvals | Non-explosion proof | Ex ia IIC T5 Ga (Using a Zener barrier) |
Power Supply | Supplied from indicator unit | |
Operating Temperature and Humidity | 0 - 40°C 30 to 85 %RH | |
External Dimensions | W300×H350×D100 mm (excluding protrusions) | |
Weight | Approx. 5.6 kg |
For Toxic Gas
Model | PS-2DP-N | PS-2DE-Ex |
Target Gas | Toxic gas | |
Sensor Type | Electrochemical cell | |
Detection Method | Pump suction type | Ejector suction type |
Detection Range | According to separate specifications | |
Compatible Cables | 2-core+2-core shield | |
Extendible distance | 2mm2 cable less than 1km | 2-core shield |
Approvals | Non-explosion proof | Using a zener barrier Ex ia IIC T5 Ga or Ex ia IIC T5X(depending on installed sensor) |
Power Supply | Supplied from indicator unit | |
Operating Temperature and Humidity | 0 - 40°C 30 to 85 %RH | |
External Dimensions | W300×H350×D100 mm (excluding protrusions) | |
Weight | Approx. 5.6 kg |
