Features
āļĢāļļāđāļāļāļĩāđāļĄāļĩāđāļŦāđāđāļĨāļ·āļāļ:
Specifications
Model | PE-2CC | PE-2DC |
Target Gas | Combustible Gas / Toxic Gas / Inert Gas | |
Sensor Type | Hot wire semiconductor / Catalytic / Thermal Conductivity | |
Detection Method | Pump suction type | |
Detection Range | As per specifications | |
Compatible Cables | 6-core shielded cable: CVV-S 0.75mm2 to 2.0mm2 | |
Extendible distance | 1km (with 2mm2 cable) | |
Explosion Proof | d2G4 | |
Sensor Power Supply | Supplied from indicator unit | |
Pump Power Supply | AC100VÂą10% | DC24VÂą10% |
Operating Temperature and Humidity | -10°Cï―40°C 30 to 85 %RH | |
External Dimensions | W122ÃH390ÃD96 mm (Excluding flow checkers and gas collector) | |
Weight | Approx. 6.2 kg |
